2026 Jeep® Cherokee near Spartanburg, SC

The 2026 Jeep® Cherokee is a four-door sport-utility vehicle classified as a multipurpose vehicle and assembled at the Toluca Assembly Plant in Mexico. It uses a transverse front-engine layout with a standard 4x4 drivetrain configuration. The vehicle is built on the STLA-Large unibody platform, which integrates structural rigidity with reduced mass through a unitized body construction. All dimensions referenced are measured at curb weight with standard tires and wheels. This platform supports the hybrid powertrain, suspension geometry, and cabin packaging of the 2026 Jeep® Cherokee while maintaining balanced weight distribution rated at 58.6 percent front and 41.4 percent rear.

Turbocharged 1.6-Liter Inline-Four with Hybrid Integration

The 2026 Jeep® Cherokee is equipped exclusively with a 1.6-liter inline four-cylinder turbocharged engine paired with an Electrified Variable Transmission system for hybrid operation. The engine features an aluminum block and aluminum cylinder heads to optimize weight and thermal efficiency. Bore and stroke measure 3.03 inches by 3.378 inches, or 77 millimeters by 85.8 millimeters. The compression ratio is 11.3 to 1. The valvetrain uses a chain-driven dual overhead camshaft configuration with variable valve timing for both intake and exhaust camshafts.

Central direct fuel injection delivers fuel precisely into the combustion chamber. The engine produces 177 horsepower at 5,500 revolutions per minute and 221 pound-feet of torque between 2,000 and 3,500 revolutions per minute. Maximum engine speed is electronically limited to 6,500 revolutions per minute. The system operates on regular unleaded gasoline rated at 87 octane. Oil capacity is 4.7 quarts or 4.6 liters. Emissions control is managed through a close-coupled catalytic converter system, and the engine complies with SULEV 30 standards. Engine start-stop technology reduces fuel consumption during idle conditions.

400-Volt Battery System and Combined Output

The hybrid system incorporates a 400-volt battery pack with a capacity of 1.08 kilowatt-hours and 4.1 amp-hours. The battery uses NCM-Graphite chemistry. Charging occurs through brake regeneration, capturing kinetic energy during deceleration and converting it into stored electrical energy. The power-split hybrid configuration integrates the gasoline engine with electric motor assistance through the electronically controlled continuously variable transmission.

Total combined system output is rated at 210 horsepower and 230 pound-feet of torque. This output represents the integrated performance of the gasoline engine and electric motor working together. Preliminary EPA fuel economy estimates are 42.2 miles per gallon in city driving, 33.2 miles per gallon on the highway, and 36.7 miles per gallon combined. The hybrid integration supports both efficiency and consistent torque delivery across varied driving conditions.

Electronically Controlled Continuously Variable Transmission

All models utilize an electronically controlled continuously variable transmission configured in a transverse layout. The transmission is designed as a power-split hybrid unit that manages the interaction between the gasoline engine and electric motor. This configuration eliminates traditional stepped gear changes and provides seamless acceleration. The final drive ratio is 4.518. Ratio spread is not specified due to the continuously variable design.

The transmission works in coordination with the hybrid system to optimize fuel efficiency and maintain smooth torque application. By continuously adjusting gear ratios, the system maintains engine operation within efficient RPM ranges while supporting acceleration demands.

Jeep® Active Drive I and Selec-Terrain® Traction Management

The 2026 Jeep® Cherokee includes Jeep® Active Drive I as standard equipment on all models. This system uses a single-speed transfer case and provides a fully disconnecting 4x2 mode that automatically engages 4x4 operation when traction conditions require it. The torque split can operate at 50 percent front and 50 percent rear, and it can automatically shift to 100 percent front torque distribution when appropriate.

Selec-Terrain® traction management includes Auto, Sport, Snow, and Sand or Mud modes. Each mode adjusts throttle response, transmission calibration, and torque distribution. The system operates without a center differential. Both front and rear axles use open differentials. This configuration prioritizes efficient operation during standard driving while maintaining traction capability for low-grip surfaces.

Suspension Geometry and Steering Calibration

The front suspension uses a MacPherson® strut design. The rear suspension uses an integral link configuration. This combination supports balanced ride control and predictable handling characteristics. The geometry is engineered to manage weight transfer during acceleration, braking, and cornering.

Steering is provided through an electric power steering rack-and-pinion system. The overall steering ratio is 15.15. The turning diameter measured curb-to-curb is 40.3 feet. Steering travel from lock to lock measures 2.57 turns. Electric assist contributes to efficiency and consistent steering response across varying speeds.

Four-Wheel Disc Braking System and Stability Controls

Braking is managed through four-wheel hydraulic disc brakes equipped with anti-lock braking capability. The front rotors measure 13.0 inches by 1.1 inches and are vented for heat dissipation. Front calipers use a dual-piston floating design with piston dimensions of 2 by 1.9 inches. The swept area for the front brakes is 158.8 square inches.

Rear rotors measure 12.6 inches by 0.47 inches and use a solid disc design. Rear calipers use a single-piston floating configuration measuring 1 by 1.7 inches. The swept area for the rear brakes is 127.77 square inches. An electronic park brake operates through a motor integrated into the rear caliper.

Electronic Stability Control is standard, as is all-speed traction control. These systems monitor wheel speed and vehicle dynamics to maintain directional stability during acceleration, braking, and cornering.

Dimensional Specifications and Structural Proportions

The 2026 Jeep® Cherokee has a wheelbase of 113.0 inches. Overall length measures 188.1 inches. Overall width at mirrors is 83.6 inches, and body width is 74.7 inches. Overall height at the roof rail and antenna measures 67.5 inches. Ground clearance is rated at 8.0 inches.

Front track width measures 64.2 inches, and rear track width measures 64.3 inches. The frontal area is 29.1 square feet, and the drag coefficient is 0.335. Aero CdA is measured at 9.7 square feet. Load floor height is 31.2 inches, and sill step height is 18.5 inches.

The approach angle is 19.6 degrees. The ramp breakover angle measures 18.8 degrees. The departure angle is 29.4 degrees. These figures define the vehicle's geometric capability during incline and obstacle transitions.

Fuel tank capacity is 13.7 gallons or 51.9 liters. Curb weight is rated at 4,295 pounds. Gross vehicle weight rating is 5,350 pounds. Maximum payload capacity is 850 pounds. Maximum towing capacity is 3,500 pounds.

Interior Dimensions and Passenger Space Metrics

The 2026 Jeep® Cherokee provides seating for five occupants with a front and rear configuration of two and three seats. Total interior passenger volume is 107.361 cubic feet. Front headroom measures 40.3 inches without the dual-pane panoramic sunroof and 38.0 inches with it. Front legroom measures 41.3 inches. Front shoulder room measures 57.7 inches, and hip room measures 55.4 inches. Seat travel measures 8.7 inches. The recliner range is 8 to 76 degrees for manual adjustment and 8 to 55.25 degrees for power adjustment.

Second-row headroom measures 40.2 inches without the panoramic sunroof and 38.1 inches with it. Second-row legroom measures 38.5 inches. Knee clearance measures 2.8 inches. Shoulder room measures 57.6 inches, and hip room measures 55.1 inches. The recliner range mirrors the front seat configuration depending on adjustment type.

Cargo volume behind the second row measures 33.622 cubic feet. Cargo volume behind the first row measures 68.335 cubic feet. Total passenger plus cargo volume measures 140.983 cubic feet. Liftover height is 31.2 inches. Maximum cargo width at the liftgate opening measures 45.2 inches. Maximum cargo height at the liftgate opening measures 28.1 inches. The distance between interior wheelhouse trim panels measures 43.4 inches.

Wheel and Tire Configurations

The 2026 Jeep® Cherokee 4x4 models use 17 by 7-inch Satin Carbon cast aluminum wheels paired with 225 by 65R17 all-season Nexen Roadian GTX tires. Limited 4x4 models use 18 by 7-inch painted diamond-cut aluminum wheels paired with 225 by 60R18 all-season Nexen Roadian GTX tires. Overland 4x4 models use 20 by 8-inch painted diamond-cut aluminum wheels paired with 235 by 50R20XL all-season Pirelli Scorpion MS tires.

Revolutions per mile are rated at 707 for the 17-inch configuration, 704 for the 18-inch configuration, and 692 for the 20-inch configuration. Each configuration supports the vehicle's traction, ride height, and handling characteristics.
